Product Features
· Straight horizontal profile for toilet side wall mounting — ADA-compliant position and length specification for accessible toilet stalls
· SUS304 or SUS316 stainless steel
· Mirror polished or satin brushed finish
· 150 kg load capacity
· 32mm or 35mm diameter (ADA-compliant)
· Concealed mounting flanges with decorative covers
· Standard lengths 600–900mm (custom available)
· OBM available — custom branding for specification projects
Product Specifications
| Model | GB-016S |
| Type | Stainless Steel Toilet Side Grab Bar |
| Material | SUS304 or SUS316 Stainless Steel |
| Diameter | 32mm or 35mm |
| Surface Finish | Mirror Polished / Satin Brushed |
| Standard Lengths | 600 / 700 / 800 / 900mm (Custom Available) |
| Load Capacity | ≥150 kg |
| Wall Clearance | 38mm |
| Mounting | Wall-Mounted, Concealed Screws |
| Standards | ADA Section 609 Compliant |
| Applications | Hotel Accessible Bathrooms, Public Restrooms, Hospital Bathrooms, Commercial Facilities |
| MOQ | By Quantity — Project Order |
| Lead Time | 15–20 Business Days |
Applications
· Hotel accessible bathroom toilet areas — mirror polished finish matches polished chrome toilet hardware in premium hotel bathrooms
· Public accessible toilet stalls — ADA-compliant side bar in new-build and refurbishment public restroom accessible stalls
· Commercial office building accessible bathrooms — employer-provided ADA compliance for accessible restroom facilities
· Hospital bathrooms — satin brushed specification for clinical grab bar applications in non-antibacterial-priority environments
FAQ
Q: What length side bar is required for ADA compliance?
A: ADA Section 604.5.2 requires the side wall grab bar to be at least 42 inches (1067mm) long, with the front end of the bar positioned at least 24 inches (610mm) from the rear wall and the rear end within 12 inches (305mm) of the rear wall. Note: this is the minimum ADA requirement — check your project's local building code for any additional requirements.
Q: When should I specify GB-016S (stainless) instead of GB-009 (nylon)?
A: Specify GB-016S for hotel and premium commercial environments where a stainless finish is required to match the bathroom hardware specification. Specify GB-009 for hospital and clinical environments where antibacterial nylon coating, warm touch and potential for color customization are preferred.
