Product Features
· Surface-mounted adhesive installation — no drilling, no wall penetration, no fixing hardware; installs with structural adhesive only
· Vinyl resin cover (PVC option available) — smooth, hygienic surface compatible with standard and hospital-grade cleaning agents
· Impact-resistant — protects wall corners from wheelchair, cart and trolley contact
· Fire-retardant — meets healthcare and public building fire safety requirements
· Antibacterial and waterproof — continuous hygiene performance for clinical environments
· Smooth edges, ergonomic profile — minimizes injury risk from incidental contact
· Customizable colors — matches existing wall finish or HR/WG Series color specification
· 3000mm standard section length
Product Specifications
| Model | CG-50A (Surface Mounted Adhesive Corner Guard) |
| Type | Single hard corner guard — wall protection corner protector |
| Length | 3000mm per section |
| Material | Vinyl / PVC (specify on order) |
| Surface finish | Smooth vinyl resin / PVC option |
| Color options | Customizable |
| Installation | Adhesive mounted — no drilling required |
| Fire rating | Flame-retardant |
| Features | Antibacterial, waterproof, impact-resistant, ergonomic design |
| Applications | Hospitals, nursing homes, clinics, schools, kindergartens, playgrounds, hotels, commercial buildings, factory workshops |
| Packaging | 3m/section, standard export packaging |
| MOQ | By linear metre |
Applications
· Rental and leased healthcare premises — no-drill installation avoids landlord wall penetration restrictions common in leased clinical space
· Heritage and listed buildings — adhesive mounting protects original wall fabric where drilling is prohibited or restricted
· Fast-turnaround renovation projects — corridors can be fitted with corner protection in a single visit with no drilling dust or disruption to clinical operations
· Tenant fit-outs in multi-occupancy medical buildings — clinics and practices fitting out leased space without structural wall modification rights
· Schools and kindergartens — quick installation during short maintenance windows (school holidays, weekends) without drilling noise or dust
· Light-to-moderate traffic corners — corridors, consulting room doorframes, and areas with lower impact frequency than main thoroughfares
Installation Steps
1. Clean the wall corner surface thoroughly — remove all dust, grease, loose paint and old adhesive residue. The substrate must be fully dry before proceeding.
2. Measure and cut the CG-50A section to the required length using a sharp utility knife and straight edge, allowing for the full height of the corner to be protected.
3. Dry-fit the section against the corner to confirm fit and alignment before applying adhesive.
4. Apply structural adhesive (contact cement or construction adhesive appropriate for vinyl/PVC-to-wall bonding) to the back of the corner guard, following the adhesive manufacturer's coverage and open-time guidance.
5. Press the corner guard firmly into position along the full length of the corner, working from top to bottom (or bottom to top) to avoid trapping air bubbles.
6. Apply firm, even pressure along the entire length — a rubber roller or firm hand pressure ensures complete adhesive contact across the full bonded surface.
7. Hold or temporarily brace the section in position for the adhesive's specified initial set time if the corner guard does not self-support immediately after pressing.
8. Allow full adhesive cure (typically 24 hours) before the corner is exposed to contact or cleaning.
9. Wipe away any adhesive residue from the wall surface immediately, before it cures, using an appropriate solvent recommended by the adhesive manufacturer.
Product Advantages
· Zero wall damage — no drilling means no risk of hitting concealed services (electrical, plumbing) and no repair required if the corner guard is ever removed
· Fastest installation in the CG Series — a single corridor corner can be protected in minutes rather than the longer process required for drilled, bracket-mounted alternatives
· Ideal for rapid-deployment and temporary healthcare facilities — field hospitals, temporary clinics and pop-up medical facilities benefit from an installation method requiring no specialist tools or structural work
FAQ
Q: Why choose CG-50B over the adhesive CG-50A?
A: Choose CG-50B when the corner is exposed to continuous, high-frequency mechanical impact — main hospital corridors, busy school hallways, areas with constant wheelchair or cart traffic. The drilled aluminum retainer provides a structural fixing that resists impact loosening over years of use in ways adhesive bonding cannot guarantee in the highest-traffic locations. Choose CG-50A when installation speed, wall preservation, or lease restrictions make drilling undesirable, and traffic levels are light to moderate.
Q: What does ASTM E84 Class A mean for this product?
A: ASTM E84 is the standard test method for surface burning characteristics of building materials, widely referenced in North American fire codes. Class A is the highest performance classification within this standard, indicating the lowest flame spread and smoke development rating. This classification supports specification in projects requiring documented fire safety compliance for interior finish materials.
Q: Can CG-50B be installed alongside HR Series handrails and WG Series wall guards in the same project?
A: Yes. CG-50B is designed to be part of a complete coordinated wall protection system. With 100+ customizable colors available, CG-50B can be color-matched to HR Series handrails and WG Series wall guards specified in the same corridor, creating a visually consistent installation from a single supplier.
